Thương hiệu | |
Model | PRIME B760M-F D4-CSM |
CPU | Intel® Socket LGA1700 for Intel® Core™14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors* |
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0** | |
* Refer to www.asus.com for CPU support list. | |
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types. | |
Chipset | Intel® B760 Chipset |
Memory | 2 x DIMM slots, Max. 64GB, DDR4 |
5333(OC) / 5066(OC) / 5000(OC) /4800(OC) / 4600(OC) / 4400(OC) / 4266(OC) / 4000(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 Non-ECC | |
Expansion Slots | Intel® Core™ Processors (14th & 13th & 12th Gen) |
1 x PCIe 4.0 x16 slot | |
Intel® B760 Chipset | |
1 x PCIe 4.0 x1 slot | |
Storage | Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* |
Intel® Core™ Processors (14th & 13th & 12th Gen) | |
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) | |
Intel® B760 Chipset | |
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) | |
4 x SATA 6Gb/s ports | |
* Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10. | |
Ethernet | 1 x Realtek 1Gb Ethernet |
USB | Rear USB (Total 6 ports) |
4 x USB 5Gbps ports (4 x Type-A) | |
2 x USB 2.0 ports (2 x Type-A)* | |
Front USB (Total 5 ports) | |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports | |
2 x USB 2.0 headers support 3 additional USB 2.0 ports | |
Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC* |
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking | |
- Supports up to 24-Bit/192 kHz playback | |
Audio Features | |
- Audio Shielding | |
- Premium audio capacitors | |
- Dedicated audio PCB layers | |
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. | |
Back Panel I/O Ports | 4 x USB 5Gbps ports (4 x Type-A) |
2 x USB 2.0 ports (2 x Type-A) | |
1 x HDMI™ port | |
1 x Realtek 1Gb Ethernet port | |
3 x Audio jacks | |
Internal I/O Connectors | Fan and Cooling Related |
1 x 4-pin CPU Fan header | |
1 x 4-pin Chassis Fan header | |
Power Related | |
1 x 24-pin Main Power connector | |
1 x 8-pin +12V Power connector | |
Storage Related | |
2 x M.2 slots (Key M) | |
4 x SATA 6Gb/s ports | |
USB | |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports | |
2 x USB 2.0 headers support 3 additional USB 2.0 ports | |
Miscellaneous | |
2 x Addressable Gen 2 headers | |
1 x Clear CMOS header | |
1 x COM Port header | |
1 x Front panel audio header (F_AUDIO) | |
1 x S/PDIF Out header | |
1 x Speaker header | |
1 x SPI TPM header (14-1pin) | |
1 x 10-1 pin System Panel header | |
BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
Form Factor | micro-ATX Form Factor |
9.6 inch x 8.3 inch (24.4cm x 21.1cm) |
