⚙️ Core Architecture

• Chipset: Intel B660
• CPU Socket: LGA 1700 (Supports 12th, 13th, and 14th Gen Intel Core, Pentium Gold, and Celeron Processors)
• Form Factor: Micro-ATX (24.4 cm x 21.1 cm)

🧠 Memory (RAM)

• Slots: 2 x DIMM slots (Dual Channel architecture)
• Type: DDR4 non-ECC, un-buffered memory
• Max Capacity: Up to 64GB
• Supported Speeds: 5333(OC) / 5000(OC) / 4800(OC) / 4600(OC) / 4400(OC) / 4000(OC) / 3200 / 3000 / 2800 / 2666 / 2400 / 2133 MHz

💾 Storage & Expansion

• M.2 NVMe Slots: 2 x M.2 slots (Key M)
  • M.2_1 slot: Supports PCIe 4.0 x4 mode (from CPU)
  • M.2_2 slot: Supports PCIe 4.0 x4 mode (from B660 chipset)
• SATA Ports: 4 x SATA 6Gb/s ports
• PCIe Slots:
  • 1 x PCIe 4.0/3.0 x16 slot (for Graphics Card)
  • 2 x PCIe 3.0 x1 slots (for expansion cards)

🔌 Rear I/O Ports

• Video Outputs: 1 x HDMI 2.1 (supports 4K@60Hz) and 1 x VGA (D-Sub)
• USB Ports:
  • 4 x USB 3.2 Gen 1 ports (Type-A)
  • 2 x USB 2.0 ports (Type-A)
• Networking: 1 x Realtek 1Gb Ethernet port
• Audio: 3 x Audio jacks (Realtek 7.1 Surround Sound High Definition Audio CODEC)
• Legacy: 1 x PS/2 Keyboard/Mouse combo port

⚡ Power & Cooling

• VRM Design: 6+1+1 Power Stages
• Power Connectors: 1 x 24-pin Main Power, 1 x 8-pin ProCool +12V Power connector
• Fan Headers: 1 x 4-pin CPU Fan header, 1 x 4-pin Chassis Fan header
